ATN BlazeTrek 6 325 Thermal Monocular

€999.00 *

Prices incl. VAT plus shipping costs

Ready to ship today,
Delivery time appr. 1-3 workdays

Order number: TIMNBLT325G6

Close menu

Product information "ATN BlazeTrek 6 325 Thermal Monocular"

384x288Thermal sensor

25mm (Ge); F/1.0Lens

2.8-22xMagnification incl. digital zoom

32 GBInternal storage

ATN · THERMAL OBSERVATION

ATN BlazeTrek 6 325

ATN BlazeTrek 6 325 combines a 384x288 thermal sensor with a 25mm (Ge); F/1.0 lens. Its 2.8-22x magnification range includes digital zoom. Manual focusing lets you adjust the image to the scene, while the compact body is easy to carry outdoors.

See the scene. Understand the detail.

The 800×600 OLED display shows the processed image. Sensor resolution and display resolution describe different parts of the device: a higher-resolution screen does not add native thermal sensor detail. Digital zoom enlarges the existing image.

ATN BlazeTrek 6 325 – manufacturer function illustration — ATN manufacturer illustration / application example

Record and share your observations

Photos and videos can be saved in the internal memory. Built-in Wi-Fi connects the device to a compatible phone or tablet. ATN lists Connect 6 for this generation.

Made for time outdoors

An internal rechargeable battery powers the unit; USB-C supports external power. ATN specifies IP67 protection. Actual battery life depends on temperature and enabled functions.

Technical specifications

Sensor Resolution	384x288
Refresh Rate	50 Hz
Thermal Sensitivity (NETD)	≤18mK
Field of View (HxV)	10.9° x 8.2°
Lens System	25mm (Ge); F/1.0
Magnification	2.8-22x
Focus	Manual (1m to infinity)
Digital Zoom	1×, 2×, 4×, 8×
Display	800×600 OLED Display
Built-in Wi-Fi Hotspot	Yes
Media Output	USB Type-C
Internal Storage Capacity	32 GB
Battery Type	Internal (rechargeable)
Battery Life	~ 8 hrs
Waterproof / IP Rating	IP67
Dimensions (L x W x H)	6.20” × 2.23” × 1.98” (158 mm × 57 mm × 50 mm)
Weight (with Battery)	320 g / 0.7 lb

Manufacturer illustrations show functions schematically and are not independent test images. Thermal imaging cannot see through solid obstacles. Detection, recognition and identification are different tasks; performance depends on the scene and weather.
