ATN BinoX 6 Dual 225 Thermal Binoculars

€1,499.00 *

Prices incl. VAT plus shipping costs

Ready to ship today,
Delivery time appr. 1-3 workdays

Order number: MSBNB6225A

Close menu

Product information "ATN BinoX 6 Dual 225 Thermal Binoculars"

256x192Thermal sensor

25 mm; F/0.9Lens

6-48xMagnification incl. digital zoom

64 GBInternal storage

ATN · THERMAL OBSERVATION

ATN BinoX 6 Dual 225

ATN BinoX 6 Dual 225 combines a 256x192 thermal sensor and a 25 mm; F/0.9 thermal lens with a separate 4K day/night channel. Switch between thermal, daytime, night and twilight viewing in one binocular. The integrated laser rangefinder adds distance measurement without a separate handheld device.

See the scene. Understand the detail.

The 0.49" OLED, 1920x1080 display shows the processed image. Sensor resolution and display resolution describe different parts of the device: a higher-resolution screen does not add native thermal sensor detail. Digital zoom enlarges the existing image.

ATN BinoX 6 Dual 225 – manufacturer function illustration — ATN manufacturer illustration / application example

Record and share your observations

Photos and videos can be saved in the internal memory. Built-in Wi-Fi connects the device to a compatible phone or tablet. ATN lists Connect 6 for this generation.

Made for time outdoors

Two replaceable 18650 batteries provide around eight hours of operation according to ATN. USB-C supports external power. ATN specifies IP67 protection. Actual battery life depends on temperature and enabled functions.

Technical specifications

Thermal Sensor Resolution	256x192
Refresh Rate	50 Hz
Thermal Sensitivity (NETD)	≤20mK
Thermal Lens System	25 mm; F/0.9
Thermal Field of View (HxV)	7.0° x 5.3°
Focus Mechanism	Manual, Front Lens Adjustment
Magnification	6-48x
Digital Zoom	1x, 2x, 4x, 8x
Day/night sensor resolution	3840x2160 Ultra HD (4K)
Display Resolution	0.49" OLED, 1920x1080 Resolution
Internal Storage Capacity	64 GB
Media Output	USB Type-C
Built-in Wi-Fi (Hotspot)	Yes
Battery	2 x 18650 Rechargeable (Replaceable)
Battery Life	~8 hrs
Weight	710 g / 1.56 lbs
Dimensions (L x W x H)	210x184.5x55 mm (8.27x7.26x2.17 in)
Waterproof / IP Rating	IP67

Manufacturer illustrations show functions schematically and are not independent test images. Thermal imaging cannot see through solid obstacles. Detection, recognition and identification are different tasks; performance depends on the scene and weather.
